2.2kWp Photovoltaic System Trina Solar with 2.5 kWh Battery Storage Pytes 4850

SKU: 815

✓︎ Complete PV set for maximum independence
✓︎ Bifacial premium solar modules in full black design
✓︎ Safe high-performance storage for day and night

Available immediately

Delivery time: ca. 3 months

1.999,00 €

incl. 0% VAT , plus

Choose tax zone / country of delivery

Pay securely via:

Question about item

Ask us your question

2.2kWp Photovoltaic System Trina Solar with 2.5 kWh Battery Storage Pytes 4850

Question about item

Ask us your question

Description

Trina Solar 2.3kWp Photovoltaic System with Pytes Battery Storage. Become independent from rising electricity prices with this perfectly matched complete system for your home. Produce, store, and use your own clean solar power highly efficiently and absolutely reliably.

Your Benefits at a Glance

Maximum savings: Use your self-generated solar power even after sunset and drastically reduce your electricity bill.
Superior aesthetics: The all-black modules enhance the look of your roof and blend seamlessly into modern architecture.
Maximum safety: State-of-the-art cell technology in the battery storage guarantees an extremely long lifespan and absolute fire safety.
Easy integration: All components of the set communicate perfectly with each other, ensuring smooth, fully automatic operation.

System Components

The Solar Modules

The bifacial glass-glass modules capture sunlight not only on the front but also on the back. This results in extremely high yields even in low-light conditions. In addition, the full black design offers a consistently elegant, dark look that integrates perfectly with any roof.

The Inverter

As the intelligent heart of the system, it reliably converts the generated direct current into usable alternating current for your household. Through its smart control, it automatically and losslessly redirects excess energy into your battery storage, so that no valuable electricity is wasted.

The Battery Storage

With this safe and durable powerhouse, you have access to your own solar energy at any time, even at night or on cloudy days. The intelligent battery management system protects the system around the clock and guarantees consistently high performance for many years.

SYSTEM OVERVIEW (Complete System)
System Type	Photovoltaic system with battery storage
Total PV Rated Power	approx. 2.3 kWp
Total Storage Capacity	2.4 kWh (nominal) / 2.5 kWh (gross class)
SOLAR MODULES (Trina Solar Vertex S Series)
Manufacturer	Trina Solar
Cell Technology	Monocrystalline (half-cut)
Power per Module	460Wp
Module Efficiency	Up to 21.8%
Dimensions (L x W x H)	approx. 1762 x 1134 x 30 mm
Weight	approx. 21.8 kg per module
Frame	Anodized aluminum alloy
BATTERY STORAGE (Pytes E-BOX 4850)
Manufacturer	Pytes
Battery Technology	LiFePO4 (lithium iron phosphate)
Nominal Voltage	48 V
Nominal Capacity	50 Ah
Energy (Nominal)	2.4 kWh
Usable Capacity	2.16 kWh (at 90% DoD)
Lifespan	> 6,000 cycles
Communication Interfaces	CAN / RS485
Dimensions (W x D x H)	440 x 440 x 117 mm
Weight	approx. 24 kg
Certifications	CE, UN38.3, IEC62619
